Crosby IP IPBK10 Lifting Clamp

The IPBK10 beam clamp is used for lifting, transferring and stacking H-Beams. A ring-center hoist eye allows for the beam flange to remain vertical. This series of clamps can be used in vertical and horizontal moving, transferring and stacking of different types of structural designs, such as H-Beams, angles, etc., depending on the application desired.

Available in capacities of 1/2 – 4 metric tons

Jaw openings available: 0.19" – 1.13”

Welded alloy steel body for strength and smaller size

Forged alloy components, where required

Individually Proof Tested to 2 times the Working Load Limit with certification

Company name (Crosby IP), logo, Working Load Limit and jaw opening permanently stamped on body

Each product is individually serialized, with the serial number and Proof Load test date stamped on body

User manual with test certificate is included with each clamp

Optional IP-5000 Stinger assembly available

Allows for easy connection between the clamp and hoist hook

Minimum WLL = 10% of Maximum WLL

For use with materials with a plate surface hardness to 279HV10, only 5% Min WLL is needed

Maintenance and repair kits are available

Manufactured by an ISO 9001 facility

All sizes are RFID equipped

Sizes and working load limits

Prices, stock and lead times on request. Every item can be supplied with a test certificate; proof-load testing in our own test house on request.
