Wire Rope Inspection Checklist: When to Discard
A wire rope inspection checks eight things: broken wires, diameter reduction, corrosion, strand distortion, bird caging, kinks, heat damage and the condition of end fittings. Any one of them past its limit means the rope is discarded — not repaired. Inspections run at three levels: pre-use, periodic and statutory thorough examination.
Wire ropes are critical components in lifting and rigging operations, but they are subject to wear and fatigue over time. Regular inspection by a competent person is essential to ensure safety and compliance with the standards that govern the rope — IS 2266 for the rope as made, IS 3973 for its care and discard, and EN 13414 or IS 12735 for slings. This guide sets out the inspection regime, the key defect classes, and how to apply the discard criteria. For the criteria themselves, clause by clause, see our companion article on wire rope discard criteria under IS 3973 and ISO 4309.
The three-tier inspection regime
Treating "inspection" as one activity is the most common gap we see in site paperwork. In practice there are three distinct tiers: the operator's pre-use check catches gross damage from the last shift; the periodic inspection tracks gradual deterioration against discard criteria; and the statutory thorough examination puts a competent person's signature — and legal accountability — behind the rope remaining in service.
| Tier | Who performs it | When | What it covers |
|---|---|---|---|
| Pre-use visual check | The operator or rigger | Before each shift or lift | Gross damage: kinks, bird caging, crushed sections, obvious broken wires, damaged terminations, missing lubrication |
| Periodic inspection | A competent person, documented | Set by duty and environment — more often for severe marine or high-cycle crane service than for light indoor work | Full length where practicable: broken-wire counts, diameter measurement, corrosion, distortion, wear at sheave and drum contact zones, internal condition where accessible |
| Statutory thorough examination | A competent person recognised under the regime that applies — the state Chief Inspector of Factories in a factory, DGFASLI (Chief Inspector of Dock Safety) at a port | Factory: at least once every twelve months (Factories Act 1948, s.29(1)(a)(iii)), or as the Chief Inspector specifies in writing. Port: every wire rope every three months, and monthly once any wire has broken (Dock Workers Regulations 1990, reg. 48(2)) | Examination against the applicable standard, the register entry and the certificate |
Key inspection points
DISCARD CHECKLIST
Broken wires: Count visible broken wires over the reference lengths the standard uses — multiples of the rope diameter, not lay lengths — and discard when the count reaches the limit in the table for that rope (IS 3973, ISO 4309; IS 12735 for slings). In dock work, the eight-diameter test in reg. 48(3) of the Dock Workers Regulations also applies.
Diameter reduction: Discard when the measured diameter, compared with the rope's recorded new diameter, reaches the limit the applicable standard sets for wear and corrosion.
Corrosion: Discard if there is visible pitting, scaling, or rust that has weakened individual wires, or evidence of internal corrosion.
Strand distortion: Discard if any strand is displaced, kinked, crushed, or otherwise deformed from its normal lay.
Bird caging: Discard immediately — the outer strands have separated and bulged, and the rope's load sharing is destroyed.
Kinking: Discard — a kink permanently deforms the rope structure and cannot be straightened without loss of strength.
Heat damage: Discard if there is any evidence of exposure to excessive heat (discolouration, melted or burnt-off lubricant, arc marks).
Cracked end fittings: Discard if any termination (thimble, ferrule, socket) shows cracks, deformation, or corrosion.
Broken wires — where and how to count
Broken wires rarely appear evenly along a rope. They concentrate where the rope works hardest: at sheave contact zones, at drum crossover points, and immediately adjacent to terminations, where the wires can no longer redistribute load. Run a cotton cloth lightly along the rope — a snagged thread finds broken wire ends faster than the eye. Then count over the reference lengths the governing document uses. Every one of them measures in rope diameters: IS 3973 and ISO 4309 count over 6d and 30d for running ropes, IS 12735 counts over 6d for slings, and the Dock Workers Regulations count over 8d at ports. None of them counts over a rope lay length, and a "per lay" figure you may have seen on a site poster matches none of them.
The permitted count is read from the table for the rope in front of you — it depends on the number of load-bearing wires in the outer strands and on whether the rope is ordinary lay or Lang's lay. Do not carry a single remembered number from rope to rope. Concentration matters as much as the count: several breaks in one strand, or at a termination, condemn a rope well before the same number scattered around it would.
Diameter, wear and internal condition
Measure the diameter across the crowns of the strands — the widest point — at several positions along the rope, and always at the same reference points on successive inspections so the trend is visible. A rope that measures progressively smaller is losing metal to abrasion, losing core support, or both. External appearance can flatter a rope: a fibre-core rope whose core has dried and collapsed, or an IWRC rope corroding from the inside out, can look serviceable while the interior is finished. This is one reason lubrication state is an inspection point in its own right — a dry rope wears internally between inspections, as explained in our wire rope lubrication guide.
Distortion, kinks and bird caging
Structural distortions — waviness, crushed sections, core protrusion, kinks and bird caging — are handling injuries rather than wear, and they do not improve with further use. Bird caging in particular is an automatic rejection: the strands have sprung away from the core and the rope's load sharing is destroyed. Waviness (IS 3973 calls it corkscrew deformation) is the one distortion the standard measures rather than condemns on sight, so measure it against the clause. Our article on bird caging of wire rope covers causes and prevention.
Photograph every defect you record, with a scale reference and the rope's ID tag in frame. When a discard decision is questioned later, a dated photograph beside the register entry ends the argument in seconds.
Inspection standards and compliance in India
Three documents frame wire rope inspection for Indian sites. IS 2266 is the manufacturing standard for steel wire ropes for general engineering purposes — it defines what a compliant rope is when new. IS 3973, the code of practice for the selection, installation and maintenance of wire ropes, carries the discard criteria for ropes in service. For ropes running on cranes, ISO 4309 is the internationally recognised code for care, maintenance, inspection and discard, and is commonly cited alongside the Indian standards on class-society and export-linked work. Note that IS 3973 prescribes no inspection interval: intervals come from the statute, the crane manual or the class society.
The statutory layer sits above the standards, and which regime applies decides who the competent person is. In a factory, section 29 of the Factories Act 1948 requires every chain, rope and lifting tackle to be thoroughly examined by a competent person at least once in every twelve months, and the competent person is recognised by the state Chief Inspector of Factories. At a port, the Dock Workers (Safety, Health and Welfare) Regulations 1990 require loose gear to be examined (reg. 47) and every wire rope to be inspected every three months, monthly after a wire break (reg. 48); there the competent person is recognised by DGFASLI as Chief Inspector of Dock Safety. On building and construction sites the BOCW Central Rules 1998 apply, with the competent person recognised by the Central Government. Our guide to DGFASLI and Factories Act compliance covers the framework, and our guide to test certificates and registers covers the paperwork itself.
Sealinkers has operated as an in-house test house in Darukhana, Mumbai since 1977, with a 1,200 T proof-load test bed. On that bed we regularly see ropes submitted for examination that pass a distance visual but fail on the first close pass — valley breaks hidden between strands, corrosion under a coat of old grease, a termination ferrule with a hairline crack. It is why we insist inspections are done slowly, on a cleaned rope, in good light, and never from the ground looking up.
Periodic inspection and records
Periodic inspections should be scheduled by the intensity of use and the environment — light indoor use needs them less often than severe service such as marine work or high-cycle cranes, where frequent checks run in addition to the operator's pre-use visual. A competent person should perform these periodic inspections and document the findings. Keeping detailed records of inspections, repairs and replacements is vital for maintaining a safe lifting environment and for the statutory register. Each record should identify the rope (certificate number, construction, diameter, length), the measured diameter at reference points, broken-wire counts by location, lubrication state, and a clear fit-for-service or discard verdict with the inspector's name and date. Matching the rope on the hook to the rope on the certificate is half the job — our guide on how to read a test certificate shows what to cross-check.
General discard triggers
The specific limits vary by standard and by rope, but the general rules do not: discard rope with broken wires beyond the table's count, severe corrosion, kinks or bird caging, heat damage, or diameter reduction past the applicable limit. Always read the applicable standard or the manufacturer's recommendations for the precise criteria, and when in doubt, replace the rope.
Wire rope is consumable rigging. If a rope shows any of the discard criteria listed above, do not use it — the cost of replacement is trivial compared to a lifting failure. Always maintain an inspection log with dated entries for every rope in service.
Frequently asked questions
Who counts as a "competent person" for wire rope inspection?
For routine periodic inspections, a competent person is someone with the training and experience to recognise defects and judge them against discard criteria — typically a senior rigger, maintenance engineer or inspection-trained supervisor. For statutory thorough examinations the competent person must be recognised for that purpose, and the regime decides by whom: the state Chief Inspector of Factories under the Factories Act, DGFASLI under the Dock Workers Regulations at ports, and the Central Government under the BOCW Rules on construction sites.
Can a wire rope with broken wires ever stay in service?
Yes — scattered individual broken wires are a normal part of a rope's fatigue life, and discard criteria are written as permitted counts over reference lengths precisely because a rope is not condemned by its first broken wire. What matters is the number, the concentration (several breaks in one strand are far worse than the same number scattered), and the trend between inspections. At the applicable limit, the rope comes out of service without debate.
How do I measure wire rope diameter correctly?
Measure across the crowns of the strands — the widest points of the rope's cross-section — not across the valleys. Take readings at several points along the rope and repeat them at the same reference points each inspection so you are tracking a trend, not a single number. A calliper with broad jaws that spans a full strand crown on each side gives repeatable readings.
Do I need to inspect a brand-new rope before first use?
Yes. A new rope should be checked against its certificate (construction, diameter, length, mill test certificate details), inspected for transit damage — crushed lays, disturbed serving, corrosion from wet storage — and installed so that no twist is introduced during reeving. Record its actual new diameter: every later diameter check is measured against it. Every rope we supply from our Usha Martin wire rope range comes with its mill test certificate for exactly this cross-check.
What happens to a rope that fails inspection?
It is removed from service immediately, physically prevented from returning (cut the eye, or tag and quarantine it), the register is updated, and a replacement is ordered against the same specification. Discarded rope should never be downgraded into an improvised sling.
Related reading
Inspection is one leg of a rope's service life — the others are correct selection and correct maintenance. Read the wire rope discard criteria for when a rope must come out of service, start with our wire rope construction guide to match rope to duty, keep it alive with the lubrication guide, and when a rope reaches discard, source its certified replacement from our Usha Martin wire ropes or ready-made wire rope slings. For certified wire ropes, inspection support, or a statutory examination slot on our test bed, contact Sealinkers for a quote.
