Crosby Western 10″ Manila Steel Shell Block – 1-1/4″ Rope – 8 Ton WLL – #702342
- Proof-load tested on request, up to 1,200 T
- Test certificate with every item
- IRS · ABS · LRS · BV certification
- Price, stock and lead time within one working day
New-style block with higher Working Load Limit
Galvanized steel shell
Laser cut sideplate opens for rope insertion
Incorporates exclusive bolt-retaining spring to assure no lost bolts, plus utilizes secondary retaining pin
Bronze bushing with larger bearing diameter for extended service…
Request a quote
Price, stock and lead time by email, usually within one working day. Ask for test certificates with your enquiry.
The Crosby Western 10" Manila Steel Shell Block – 1-1/4" Rope – 8 Ton WLL is part of the Crosby block range. Sealinkers supplies it from Mumbai with documentation on request.
New-style block with higher Working Load Limit
Galvanized steel shell
Laser cut sideplate opens for rope insertion
Incorporates exclusive bolt-retaining spring to assure no lost bolts, plus utilizes secondary retaining pin
Bronze bushing with larger bearing diameter for extended service life
Lubricated center pin
Utilizes Crosby "N" style hooks with integrated latch (latch kit is replaceable)
Meets or exceeds all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements–importantly, these blocks meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
Prices, stock and lead times are quoted on request. Use the quote form or WhatsApp on this page, and ask for test certificates with your enquiry.
