The Crosby M24-3.00 x 35.40 mm HR-1000M Swivel Hoist Ring – 4200 kg WLL is part of the Crosby swivel range (catalogue no. 1068361). Sealinkers supplies it from Mumbai with documentation on request.
All components are alloy steel, Quenched and Tempered
Forged bail is made of alloy steel for extra durability and includes a Product Identification Code (PIC)
Bail has a larger throat opening than the popular HR-125 model
The Working Load Limit and recommended torque value are permanently stamped into the washer
Individually proof-tested to 2-1/2 times the Working Load Limit with certification and Statistically Magnetic Particle inspected
Rated at 100% of Working Load Limit at any angle.
Specifications
| Catalogue description | HR1000M M24X90MM HVY LIFT SWIV.HOIST RNG |
|---|---|
| Crosby product no. | 1068361 |
Prices, stock and lead times are quoted on request. Use the quote form or WhatsApp on this page, and ask for test certificates with your enquiry.
