The Crosby 1" G-213 Round Pin Anchor Shackle – 8-1/2 Ton WLL is part of the Crosby shackle range. Sealinkers supplies it from Mumbai with documentation on request.
Forged, Quenched & Tempered, with alloy pins
Working Load Limit permanently shown on every shackle
Hot-dip galvanized
Sizes 3/8" and below are mechanically galvanized
Fatigue rated to 20,000 cycles at 1-1/2 times the Working Load Limit
Shackles can be furnished proof tested with certificates to designated standards, such as ABS, DNV, Lloyds, or other certification; charges for proof testing and certification available when requested at the time of order
Shackles are Quenched & Tempered and can meet DNV impact requirements of 42 Joules (31 ft-Ib) at -20° C (-4° F)
G-213 Round pin anchor shackles meet the performance requirements of Federal Specification RR-C-271H, Type IVA, Grade A, Class 1, except for those provisions required of the contractor
DO NOT SIDE LOAD ROUND PIN SHACKLES
Look for the Red Pin®… the mark of genuine Crosby quality.
Prices, stock and lead times are quoted on request. Use the quote form or WhatsApp on this page, and ask for test certificates with your enquiry.
