The Crosby IP IPBK10 2 Ton Lifting Clamp is part of the Crosby lifting clamp range (catalogue no. 2703838). Sealinkers supplies it from Mumbai with documentation on request.
The IPBK10 beam clamp is used for lifting, transferring and stacking H-Beams. A ring-center hoist eye allows for the beam flange to remain vertical. This series of clamps can be used in vertical and horizontal moving, transferring and stacking of different types of structural designs, such as H-Beams, angles, etc., depending on the application desired. Available in capacities of 1/2 – 4 metric tons
Jaw openings available: 0.19" – 1.13”
Welded alloy steel body for strength and smaller size Forged alloy components, where required Individually Proof Tested to 2 times the Working Load Limit with certification
Company name (Crosby IP), logo, Working Load Limit and jaw opening permanently stamped on body
Each product is individually serialized, with the serial number and Proof Load test date stamped on body User manual with test certificate is included with each clamp Optional IP-5000 Stinger assembly available Allows for easy connection between the clamp and hoist hook Minimum WLL = 10% of Maximum WLL For use with materials with a plate surface hardness to 279HV10, only 5% Min WLL is needed Maintenance and repair kits are available
Manufactured by an ISO 9001 facility
All sizes are RFID equipped.
Specifications
| Crosby product no. | 2703838 |
|---|---|
| Catalogue description | IPBK10 2T 5-25MM LIFTING CLAMP |
Prices, stock and lead times are quoted on request. Use the quote form or WhatsApp on this page, and ask for test certificates with your enquiry.
